Sturdy and durable tower body

Cooling tower wind cylinder, shell and water collector are all corrosion resistant, impact resistant and not easy to deformation of FRP materials, its surface with excellent stability, aging resistant imported gelcoat from Germany, with uv resistance, beautiful, durable, flame retardant, long service life and other characteristics.



High strength, stable steel frame structure

The frame made of steel has the characteristics of light weight, high strength, good rigidity, weak resonance and good stability during opening and stopping.All steel structural parts have been pickled and hot-dip galvanized treatment, good anti-rust and anti-corrosion performance, to ensure that the cooling tower can operate normally in any environment, to avoid the tower structure aging and corrosion.The tower structure can withstand wind pressure up to 180Kgf/m2 and earthquake of magnitude 8.



Energy-saving, efficient heat exchange system

German AXIMA patented flame retardant filler: the filler unique with its own efficient water collector and louver device set modified polyvinyl chloride plastic (PVC) as raw material, the use of Germany AXIMA unique modified formula processing out of the filler, with corrosion resistance, high temperature resistance, long service life and other characteristics.The packing structure with AXIMA patented technology, on the one hand, improves the heat exchange efficiency between water and air, and on the other hand, minimizes the water drift rate.The standard temperature of packing can reach 65℃.



Low consumption, low noise transmission system

1. ABB motor or Siemens outdoor fully enclosed motor is adopted by ehima, which has the characteristics of low noise, stable performance, high protection level and long service life, and can be equipped with double-speed motor or frequency conversion control system according to the requirements of users.

2, Italy clay, phil wing fan fan, its blades made from aluminum alloy material, low speed, wide string leaf, large curve, with uniform wind speed, low noise, little eddy current, high efficiency, etc. In the case of low rotating speed of the fan can get enough smoke air volume, also can adjust the blade Angle according to the different climate conditions.Therefore, the cooling tower can not only meet the operating requirements of users under harsh working conditions, but also adjust the blade Angle in different seasons to achieve the purpose of energy saving and consumption reduction.

3. EWX series cooling tower adopts integral sealing transmission system.Bearings for imported brands, and with multi - layer waterproof protection.Drive belt choose Japanese samsung brand, waterproof, anti - slip, long service life.



◇ water distribution system

Square cross-flow cooling tower adopts natural gravity pool water distribution system, equipped with AXIMA patented sprinkler head, with the characteristics of even water distribution, low water pressure, no blockage, etc. The water flow can be evenly dispersed on the packing to ensure full heat exchange.



◇ water collection system

Square cross flow cooling tower packing with efficient water collector and louver device, can effectively prevent floating water, is the most ideal cooling tower water collection system in Europe.
